Intro: Secret tools in power electronic devices
Silicon-controlled rectifiers (SCRs), likewise called thyristors, are semiconductor power gadgets with a four-layer triple junction framework (PNPN). Since its intro in the 1950s, SCRs have actually been commonly made use of in commercial automation, power systems, home appliance control and other areas due to their high endure voltage, huge present carrying capacity, fast response and easy control. With the growth of technology, SCRs have developed into many kinds, consisting of unidirectional SCRs, bidirectional SCRs (TRIACs), turn-off thyristors (GTOs) and light-controlled thyristors (LTTs). The distinctions in between these kinds are not only reflected in the structure and functioning concept, but likewise identify their applicability in various application circumstances. This post will start from a technical perspective, incorporated with certain criteria, to deeply examine the major differences and common uses these 4 SCRs.
Unidirectional SCR: Basic and steady application core
Unidirectional SCR is one of the most basic and typical type of thyristor. Its structure is a four-layer three-junction PNPN plan, including 3 electrodes: anode (A), cathode (K) and gateway (G). It just permits current to move in one direction (from anode to cathode) and switches on after eviction is activated. When switched on, also if eviction signal is gotten rid of, as long as the anode current is greater than the holding present (generally much less than 100mA), the SCR remains on.
(Thyristor Rectifier)
Unidirectional SCR has solid voltage and existing tolerance, with an onward recurring peak voltage (V DRM) of approximately 6500V and a rated on-state average existing (ITAV) of approximately 5000A. For that reason, it is commonly made use of in DC electric motor control, commercial heating systems, uninterruptible power supply (UPS) rectification parts, power conditioning gadgets and various other celebrations that call for constant transmission and high power handling. Its advantages are straightforward structure, low cost and high integrity, and it is a core component of lots of traditional power control systems.
Bidirectional SCR (TRIAC): Suitable for a/c control
Unlike unidirectional SCR, bidirectional SCR, additionally known as TRIAC, can achieve bidirectional conduction in both positive and negative half cycles. This framework consists of 2 anti-parallel SCRs, which enable TRIAC to be activated and switched on at any time in the AC cycle without altering the circuit connection method. The in proportion transmission voltage series of TRIAC is normally ± 400 ~ 800V, the maximum tons current is about 100A, and the trigger current is less than 50mA.
As a result of the bidirectional transmission features of TRIAC, it is specifically suitable for AC dimming and rate control in house devices and consumer electronic devices. For instance, tools such as light dimmers, fan controllers, and a/c follower speed regulatory authorities all rely upon TRIAC to attain smooth power guideline. Additionally, TRIAC likewise has a lower driving power need and is suitable for integrated layout, so it has been extensively utilized in smart home systems and tiny appliances. Although the power thickness and changing rate of TRIAC are not comparable to those of brand-new power devices, its inexpensive and convenient use make it a vital player in the area of little and moderate power air conditioner control.
Entrance Turn-Off Thyristor (GTO): A high-performance agent of energetic control
Gateway Turn-Off Thyristor (GTO) is a high-performance power device established on the basis of standard SCR. Unlike normal SCR, which can only be switched off passively, GTO can be turned off actively by applying an unfavorable pulse present to the gate, hence attaining even more versatile control. This attribute makes GTO do well in systems that require constant start-stop or quick action.
(Thyristor Rectifier)
The technical parameters of GTO reveal that it has very high power dealing with capacity: the turn-off gain has to do with 4 ~ 5, the maximum operating voltage can get to 6000V, and the maximum operating current is up to 6000A. The turn-on time is about 1μs, and the turn-off time is 2 ~ 5μs. These performance signs make GTO extensively made use of in high-power scenarios such as electric engine traction systems, big inverters, industrial electric motor frequency conversion control, and high-voltage DC transmission systems. Although the drive circuit of GTO is reasonably intricate and has high changing losses, its performance under high power and high vibrant feedback demands is still irreplaceable.
Light-controlled thyristor (LTT): A trusted choice in the high-voltage isolation atmosphere
Light-controlled thyristor (LTT) utilizes optical signals as opposed to electrical signals to cause conduction, which is its most significant function that identifies it from other kinds of SCRs. The optical trigger wavelength of LTT is typically in between 850nm and 950nm, the response time is gauged in milliseconds, and the insulation level can be as high as 100kV or above. This optoelectronic seclusion system significantly enhances the system’s anti-electromagnetic interference ability and safety.
LTT is primarily utilized in ultra-high voltage direct current transmission (UHVDC), power system relay protection gadgets, electro-magnetic compatibility protection in medical equipment, and military radar interaction systems and so on, which have exceptionally high requirements for safety and security and security. For instance, many converter terminals in China’s “West-to-East Power Transmission” task have taken on LTT-based converter shutoff modules to ensure steady operation under incredibly high voltage problems. Some progressed LTTs can additionally be integrated with gate control to attain bidirectional transmission or turn-off features, additionally expanding their application range and making them an optimal choice for solving high-voltage and high-current control issues.
